    Multi Conductor Data Bus Cable Rigid Strander High Speed Tubular Stranding Machine

    Multi-Conductor Date Bus Cable Rigid Strander, High Speed Tubular Stranding Machine


    1.Application
    The machine is used for stranding insulated cable core of control cable and steel wire armoring for cable.
    Control Cables Assembly with Back Twist
    Signal Cables Assembly with Back Twist
    Insulated Cables Assembly such as Robot Cables with Back Twist.


    Main parts

    • 630 stationary pay-off
    • Wire guiding stand
    • 54B cage
    • Die holder
    • F400/4 taping head
    • Mechanical meter counter
    • F2000 Dual wheel capstan
    • F1600 Portal type take-up
    • Mechanical transmission system
    • Electrical control system
    • Safety fence


    Mechanical and electrical components

    • The bearings are from Ha Erbin, Wa Fangdian and Luoyang brand.
    • Motors are from Chinese famous products.
    • AC driver is from Danfoss brand.
    • DC driver is from SSD Parker 590 series brand.
    • PLC is from Siemens.
    • Touch screen is from Siemens.
    • Main low voltage electric components are from high quality and well-known Chinese brand.
    Model (Rigid Stranding Machine)JLK-500JLK-630JLK-710/720
    Diameter of single wireCopperφ1.5-5 mmφ1.5-5 mm φ1.5-5 mm
    Aluminumφ1.5-5 mmφ1.5-5 mmφ1.5-5 mm
    Maximum stranded conductor ODφ35-55 mmφ35-55 mmφ35-55 mm
    Stranding Pitch6 Bobbin Stranding Cage40-719 mm51-896 mm54-963 mm
    12 Bobbin Stranding Cage40-719 mm51-896 mm54-963 mm
    18 Bobbin Stranding Cage44-793 mm63-1056 mm57-1012 mm
    24 Bobbin Stranding Cage51-924 mm71-1246 mm66-1190 mm
    30 Bobbin Stranding Cage57-1028 mm87-1553 mm79-1403 mm
    Rotating Speed6 Bobbin Stranding Cage230.6 r/min180.1 r/min150.6 r/min
    12 Bobbin Stranding Cage230.6 r/min180.1 r/min150.6 r/min
    18 Bobbin Stranding Cage208.5 r/min155 r/min142.6 r/min
    24 Bobbin Stranding Cage179 r/min130.1 r/min122.3 r/min
    30 Bobbin Stranding Cage161.8 r/min115.9 r/min102.7 r/min
    CapstanCapstan Wheel Diameter2000 mm2000 mm2000 mm
    Maximum Haul-off Force30 T30 T40 T
    Pre-spiral DevicePitch500-2500mm500-2500mm500-2500mm
    Motor Power90-180 KW110-180 KW130-180 KW
    Bobbin Size500*375*127630*475*127710*530*127
    Center Payoff Bobbin1600*800*801600*800*801600*800*80
    Take-up Bobbin2500*1500*1252500*1500*1253150*1900*160
    Maximum Haul-off Linear Speed69 m/min69 m/min62 m/min
    Central Height1000 mm1100 mm1100 mm
