    High Performance Disc Type Copper Wire Screening Machine 315/48 Bobbins

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : 3150/48
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    High Performance Disc Type Copper Wire Screening Machine 315/48 Bobbins

    High performance Disc Type Copper Wire Screening Machine 315/48 Bobbins


    Application:

    This machine is mainly used for copper wire screening for power cable and stranding of insulated wire.


    Features:

    Payoff bobbin size: 300-630, No of bobbin:60-120.

    With mechanical tension feedback device. The device guarantees the constant tension.

    Cage with multiple wire-break protections.

    Application industry Power cable copper wire screening, Communication cable copper wire screening, Control cable copper wire screening.


    Max OD of center coreΦ40mm
    Wire diameter

    Φ1.0-5.0mm Steel,

    Φ1.8-5.0mm Al,

    Rotation speed50r/min
    Line speed30m/min
    Armoring pitch100-600mm(buyer provide)
    Pay-off bobbin size in cagePN500
    Center Pay-off bobbin sizePN1600-PN3150(customer self-prepare)
    Take-up bobbin sizePN1600-PN3150(customer self-prepare)
    Capstan wheel dia.Φ2000mm
    Cage rotation motor power55KW (AC motor)
    Capstan motor power30KW (AC motor)
    Machine center high1000mm
    Total power120kw

    Main components:


    PN3150 pay-off1 set
    # type through wire frame1 set
    48-315 main cage1 set
    Assembling die holder1 set
    Post Straightener1 set
    Meter counter1 set
    Φ2000mm capstan1 set
    PN3150 Take-up1 set
    Electrical control system1 set
    Safety fence1 set

    Electrical control system
    4.11.1 The power supply is three-phase five wire system: 415V (± 10%) 50Hz
    4.11.2 The machine adopts sub motor drive (the motor adopts variable-frequency motor), each AC variable-frequency motor adopts frequency converter to control speed regulation, the whole machine control is managed by Siemens programmable controller, Siemens touch screen controls operation, and the host starts after the alarm bell rings.
    4.11.3 This machine is equipped with the following protections
    4.11.4 Frequency converter fault alarm.
    4.11.5 Overload protection and power supply protection of winding and arranging lines.
    4.11.6 Air pressure undervoltage protection.
    4.11.7 Break wire protection.

    High Performance Disc Type Copper Wire Screening Machine 315/48 Bobbins
