    Efficient Twisting Machine 380V Voltage Low Maintenance Rigid Strander

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : 630/6+12+18+24
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Efficient Twisting Machine 380V Voltage Low Maintenance Rigid Strander

    Efficient Twisting Machine 380V Voltage Low Maintenance Rigid Strander


    Product Description:

    The rigid stranding machine is an advanced and powerful machine designed to process a wide range of materials such as steel and other high-capacity materials. It features a large size and high power to deliver high-capacity output with precise and automatic control. This machine is widely used for double-twisting and twist-bunching applications, as well as double-twist bunching for high-speed production. With its advanced technology, it can produce high-quality products at a faster rate and with superior efficiency. The Double Twist Bunching Machine is designed for maximum performance, safety, and durability. It is a reliable and cost-effective solution for your production needs.

    Features:

    • Product Name: Rigid stranding machine
    • Operation: full automatic
    • Voltage: 460V/380V
    • Capacity: High Capacity
    • Material: Steel,Al, Cu.

    Technical Parameters:

    Input wire diameterCopper Ø 1.5-Ø 5.0mm
    Aluminum Ø 1.8-Ø 5.0mm
    Max stranding ODØ 45mm
    Max rotation speed6 bobbins230r/min(
    12bobbins198r/min(
    18 bobbins178r/min
    24 bobbins158r/min
    Stranding cage motor power6 bobbins75KW(AC)
    12 bobbins75KW(AC)
    18 bobbins75KW(AC)
    24 bobbins75KW(AC)
    Stranding pitch(set one PLC)Stepless adjustable
    Traction line speedMax 61m/min
    Capstan motor power90KW(AC)
    Pay-off bobbin size in cagePND630
    Forceful dual wheel capstanØ 2000mm
    Central pay-off bobbin sizePND500-630
    Take-up bobbin reel sizePN1250-PN2500
    Machine center high1000mm

    Applications:

    This machine is mainly used to produce large section and large length steel cored aluminum strand and aluminum alloy wire; It can also be used for pressing of copper round and aluminum sector conductor

    Customization for brand:

    Bearing brand(HRB)
    Low voltage appliance brand(Schneider)
    Brand of pneumatic component(AIRTAC)
    Brand of main drive motor(Jinaghuai)
    Brand of take-up motor(Jianghuai)
    Brand of inverter(Inovance)
    Touch screen(Siemens)
    PLC(Siemens)
    Bolt grade8.8 class

    Support and Services:

    BEYDE Rigid stranding Machine Technical Support and Service

    We offer technical support and service for our Rigid stranding Machine. Our team of engineers and technicians have extensive experience in the field and are available to answer your questions and help troubleshoot any issues you may have. We provide phone, email, and on-site support for our customers.

    Our technical support team can provide assistance with installation, commissioning, system setup, and maintenance. We are also able to provide spare parts and replacement components for our Rigid stranding Machine. We offer comprehensive maintenance and repair services, as well as preventative maintenance services.

    We are committed to providing the highest level of customer service and support for our Rigid stranding Machine. If you have any questions or would like to learn more about our technical support and service options, please do not hesitate to contact us.

    Packing and Shipping:

    Packaging and Shipping for Rigid stranding Machine

    When shipping a Rigid stranding Machine, the following steps should be taken to ensure the safety and integrity of the product:

    • Remove all tools and accessories from the machine
    • Ensure that all moving parts are securely locked in place
    • Clean the machine thoroughly and inspect for any damage
    • Wrap the machine in protective packaging material such as packing foam, bubble wrap, or shrink wrap
    • Place the machine in a shipping container with adequate cushioning material
    • Securely tape the container shut and label with the appropriate shipping information
    • Send the package to the designated recipient.
