    Back Twist Planetary Stranding Machine 100-150kg/H

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : 630/6+12
    Certification :
    Payment Terms : L/C, T/T
    Supply Ability : 120 Set/Year
    Delivery Time : 90 Days after receive deposit
    • Product Details
    • Company Profile

    Back Twist Planetary Stranding Machine 100-150kg/H

    Planetary Strander Machines Manufacturers In China


    1. Description

    • Cage type stranding machine is worked with 100% back twist movement.It is suitable for steel core aluminum stranding
    • wires, aluminum clad steel, bare copper, bare aluminum, power optical cable and stranding of other wire materials.
    • It can be used as laying up of 19/37 cores control cable and steel wire armoring cable.
    • It adopts magnetic hysteresis tension controller to provide bobbin tension. A set of bobbin bottom diameter detector is
    • installed in each section of the cage to automatically detect the change of the position from full bobbin to empty bobbin,
    • and then feed back to PLC, which adjusts the output torque of magnetic hysteresis tension controller to ensure constant
    • tension.
    • DC main motor drives the stranded body through the ground shaft or AC induction servo motor drives each segment
    • of the stranded body.
    • The machine adopts MMI+PLC control system, pre-setting stranding pitch, stranding direction, automatic tension
    • control and synchronous control of traction and take-up.
    • The machine provides loading-crane and loading-car for selection.
    • It can be equipped with maximum 24 filling devices according to customer requirements.


    2. Technical Parameter
    Model500630

    Diameter of single wire

    CopperΦ1.5~Φ3.0Φ1.5~Φ5.0
    AluminumΦ1.8~Φ4.0Φ1.8~Φ5.0
    Insulated coresΦ3.0~Φ8.0Φ3.0~Φ10.0
    Maximum stranded conductor ODΦ45Φ50
    Stranding lay length Step-less, adjustable

    Maximum rotating speed

    6B10070
    12B10070
    18B7062
    24B6250

    Capstan

    (m/min)

    Maximum pulling speed

    5142
    Payoff reel in cagePN500/PND500PN500/PND500

    Center payoff reel

    PN800/PN1600PN800/PN1600
    Take-up reelPN1600/PN2500PN1600/PN2500
    Central height10001000

    BEYDE is a subsidiary of Hebei HEXING electrical machinery Co., Ltd., a professional manufacturer and exporter of cable equipment. Founded in 1983 by Mr. Chen Yuke, grandfather of current president Mr. Chen Jiuzhang, HEXING has a well-equipped factory with an area of 10,000 square meters located in Hejian, Hebei province, home to the manufacture of cable machinery and equipment. HEXING is a well-known brand in China's cable industry, serving over 70% cable manufacturers in northern China.


    BEYDE supplies all types of machines including Laying-up machine, Rigid Stranding Machine, Tubular Stranding Machine, Planetary Stranding Machine and help wire & cable manufacturers lower production cost and ensure quality of final products.


    BEYDE was established for export business of HEXING as a result of increasing OEM business of HEXING for many Chinese exporters. With maturetechnological expertise, BEYDE provides cost-effective solutions for wire & cable manufacturers to expand or update their production lines
