    Skip / Bow Cable Stranding Machine 7 Strand Or Flexible High Speed

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : 630 1+6
    Certification :
    Payment Terms : L/C, T/T
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Skip / Bow Cable Stranding Machine 7 Strand Or Flexible High Speed

    High Speed Skip / Bow Stranding Machines 7 Strand or Flexible


    Heavy duty frame for high speed stability

    Dynamic balance rotor supported by double bearing

    Timing belt drive for each rotor

    Specially designed steel bow

    Hardening die steel roller for steel wire passing

    Efficient and fast

    The circuit driven by AC motor adopts electronic or mechanical synchronization between circuit components

    Centralized lubrication system

    Equipped with HMI / PLC

    Simple positioning

    Ergonomically designed operator control station

    Range of income and remuneration available

    No ply change during power failure

    Model Main Specification
    GJ630
    GJ 800
    GJ 1000
    GJ1250
    GJ 1400GJ
    1600
    Single Wire Diameter
    3mm-11mm
    4mm-13mm
    5mm-15mm
    6mm-16mm
    7mm-18mm
    8mm-20mm
    Max Stranded Diameter
    35mm
    40mm
    45mm
    50mm
    55mm
    60mm
    Stranding Pitch
    360-1750mm
    480-2000mm
    600-2250mm
    600-2250mm
    840-2750mm
    960-3000mm
    Cage Rotate Speed
    200RPM
    185RPM
    150RPM
    130RPM
    120RPM
    100RPM
    Max Line Speed
    350M/MIN
    370M/MIN
    338M/MIN
    325M/MIN
    330M/MIN
    300M/MIN
    Capstan Wheel Diameter
    800mm
    800mm
    1300mm
    1500mm
    1800mm
    2000mm
    Pay Off Drum Size In Cage
    PN630
    PN800
    PN1000
    PN1250
    PN1400
    PN1600
    Central Pay Off Drum Size
    PN630
    PN800
    PN1000
    PN1250
    PN1400
    PN1600
    Take Up Drum Size
    PN800-1600mm
    PN800-1600mm
    PN1000-2000mm
    PN1000-2000mm
    PN1000-2000mm
    PN1250-2500mm
