Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution

Beyde Trading Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now
    Buy cheap Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution from wholesalers

    Buy cheap Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution from wholesalers
    • Buy cheap Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution from wholesalers
    • Buy cheap Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution from wholesalers
    • Buy cheap Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution from wholesalers

    Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : DIN2000
    Certification :
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution

    Electrical Cable Stranders & Laying-Up Machine One-Stop Solution Round Or Fan-Shaped Cables.


    1. Application of the machine
    This machine is widely used in the various sections of the three core, four core, five core plastic power cables, XLPE cable (cross-linked polyethylene cable) and armored cable. The shape of the wire core can be round-shaped, fan-shaped and W-shaped.
    This machine is advanced performance, strong practicability, beautiful appearance and easy operation.

    Product Description
    Our advantage:
    1.Can strand cable very fast.Cage speed can be 50r/min.
    2.Have protective system for breaking wire and cable.
    3.Best after-sales service.Will give our service within 1 days.
    4.Will give you professional instruction to how to manage these machines.
    5.Good quality for testing.


    The main technical parameters

    cradle laying up machine from beyde trading
    No.Parameter nameUnit

    CLY

    630 Type

    CLY1000 TypeCLY1250 TypeCLY1400 TypeCLY1600 Type
    1Wire-core cross section areamm21.5-1610-12016-18525-24050-400
    2Max cabling diametermm40506080100
    3Cage speedr/min24.6-56.5
    (6 stage)
    11.1-26.1
    (6 stage)
    9.5-21.5
    (6 stage)
    6.8-14.5
    (6 stage)
    4.3-9.6
    (6 stage)
    4Cabling pitchmm90-280090-2900180-3000278-4700448-7600
    5Cable speedm/min2.4-33.1
    (16 stage)
    2.2-32.7
    (32 stage)
    3.87-29.4
    (36 stage)
    4.3-32.7
    (36 stage)
    4.3-32.7
    (36 stage)
    6Pay-off bobbinmmPN630PN1000PN1250PN1400PN1600
    7Take-up bobbinmmPN100-PN1600PN100-PN2000PN100-PN2000PN125-PN2500PN140-PN2800
    8Armoring head speedr/min191-781
    (9 stage)
    108-444
    (9 stage)
    108-444
    (9 stage)
    108-444
    (9 stage)
    108-444
    (9 stage)
    9Armoring pitchmm3-1735-3028-2729-3029-302
    10Taping head speedr/min139-568
    (9 stage)
    81-323
    (9 stage)
    81-323
    (9 stage)
    81-323
    (9 stage)
    81-323
    (9 stage)
    11Taping pitchmm4-2386-40312-36213-40313-403
    12Central heightmm10001000100010001000

    Quality Round Or Fan Shaped Cables Rigid Strander Electrical One Stop Solution for sale
