    Large Bearing Type 400/1+6 Tubular Stranding Machine Plc For Steel Wire Rope

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : 630 1+6
    Certification :
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Large Bearing Type 400/1+6 Tubular Stranding Machine Plc For Steel Wire Rope

    Large Bearing Type 400/1+6 Tubular Stranding Machine For Steel Wire Rope Or Galvanized Steel Wire Strand

    • This Wire Twisting Machine are used for production of stainless steel wire rope and galvanized steel wire rope.
    • This wire and rope twisting machine are double twist machine, Double output than Single twisting machine
    • It can be used for production of fine wire rope with structure of 1+6/1*7 and 1+12/1*19 with maximum diameter 1.5 mm
    • Our Wire Twisting Machine is designed at 3500 RPM, running at about 3000 RPM.
    • The output of Wire twisting machine is 3 times than single twisting machine at same speed, but with lower energy consumption, less space spend.

    • This new designed double twister standing machine are designed for steel wire rope industry
    • “Safe”, “High efficiency”, “Smart” double twist stranding machines
    • Visualization for output design
    • High speed design for high output
    • Immediately stop meet European safety standard
    • European Technology with good quality
    o.Parameter nameUnitJGG400/6+1 TypeJGG500/6+1 TypeJGG630/6+1 Type
    1Wire-core diametermmCopper 1-4
    Aluminium 1.5-5
    Copper 1.4-4
    Aluminium 1.5-5
    Copper 1.5-4
    Aluminium 1.8-5
    2Max Wiring diametermm202530
    3Cage speedr/min900800700
    4Wiring pitchmm20-28522-32924-365
    5Wire speedm/min18-256.517.6-263.216.8-138.4
    6Pay-off bobbinmmPN400PN500PN630
    7Take-up bobbinmmPN800-PN1600PN800-PN1600PN800-PN1600
    8Taping head speedr/min128-2380
    (No stage)
    300-2155
    (No stage)
    250-2000
    (No stage)
    9Taping pitchmm7-20048-8778-1022
    10Central heightmm700700700
