    Portal Type Stranding Drawing Cable Extruder Machine Take Up And Pay Off

    Ask Lasest Price
    Brand Name : Beyde
    Model Number : DIN2000
    Certification :
    Payment Terms : L/C, D/A, D/P, T/T
    Supply Ability : 200 set/year
    Delivery Time : 90 days
    • Product Details
    • Company Profile

    Portal Type Stranding Drawing Cable Extruder Machine Take Up And Pay Off

    Winding Wire And Cable Machinery Cable Extruder Machine Portal Type Take Up And Pay Off


    1. Application for Power Wire Cable Portal Type Gantry Traversing Take Up Making Machine :

    This equipment is applicable to Winding and coiling all kinds of cable into a bobbin.

    2. Technical parameters for Power Wire Cable Portal Type Gantry Traversing Take Up Making Machine :

    ModelΦ630/1250Φ800/1600Φ1000/2000Φ1250/2500Φ1600/3150Φ1600/3500
    Cable Dia. (mm) Max355070100120130
    Bobbin flange dia. (mm)Φ630-1250Φ800-1600Φ1000-2000Φ1250-2500Φ1600-3150Φ1600/3500
    Bobbin overall width (mm)475-950600-1180750-1500950-19001180-23001180-2300
    Load capacity ( T)34-86-1012-1515-2018-20
    Line speed (m/min) Max1008080656050
    Traverse precision (%)1-21-21-21-21-21-2

    3. Features for Power Wire Cable Portal Type Gantry Traversing Take Up Making Machine:

    A. Portal shaped structure, Electrical compacting or relaxing reels and lifting. It has function of lifting together, drop together, lifting separate and drop separate..

    B. Portal shaped stand traverses wire locomotive, which is driven by AC motor and controlled by transducer. The traverse speed follows the take-up speed, that make the traversing pitch adjustable step-less. It is with the function of traverse quickly and adjustment.

    C. Bobbins clamping protection, the limited protection of up and down bobbins and terminal protection of transverse movement

    D. Semi-automatic operating saving time and label.

    Portal Type Stranding Drawing Cable Extruder Machine Take Up And Pay OffPortal Type Stranding Drawing Cable Extruder Machine Take Up And Pay OffPortal Type Stranding Drawing Cable Extruder Machine Take Up And Pay OffPortal Type Stranding Drawing Cable Extruder Machine Take Up And Pay Off
