    630-1000 Cantilever Single Twisting Machine For CAT5 / Cat6 HDMI Optical Wire

    Ask Lasest Price
    Brand Name : BEYDE
    Model Number : 630-1000
    Certification :
    Payment Terms : L/C, T/T
    Supply Ability : 200 SET
    Delivery Time : 40 DAYS
    • Product Details
    • Company Profile

    630-1000 Cantilever Single Twisting Machine For CAT5 / Cat6 HDMI Optical Wire

    630-1000 Cantilever Single Twisting Machine For CAT5,Cat6 HDMI Optical Wire


    Product Application
    This series machine is used for twisting bare copper, tinned wire and enameled wire, etc which mainly applicated in the wire and cable industry.

    Specifications
    Machine TypeΦ630Φ800Φ1000Φ1250
    PurposeIt is used in high-frequence wire, data wire, electical core wire and kinds of group standing
    Core wire specificationΦ0.6-3.0mmΦ0.8-3.0mmΦ1.0-5.0mmΦ1.0-6.0mm
    Twisting out diaMax.Φ12mmMax.Φ20mmMax.Φ25mmMax.Φ30mm
    Pitch scope20mm-200mm30mm-300mm30mm-350mm30mm-450mm
    Max rpmMAX 1000rpmMAX 800rpmMAX 500rpmMAX 400rpm
    Power15HP Frequency conversion motor20HP Frequency conversion motor25HP Frequency conversion motor30HP Frequency conversion motor
    Size of take upΦ630Φ800Φ1000Φ1250
    Size of Pay OffΦ400mm-630mmΦ400mm-630mmΦ400mm-800mmΦ400mm-800mm
    Pay off typeHorizontal dual-line pay off unit
    Taping deviceCan be freely for "S" or "Z" style charged, Wire rotating disk dia.250mm,
    Apply for material cotton paper, mylar aluminum-foil.
    Brake DevicePnenumatic tape brake device
    Electrical controlAuto-controlled and track by PLC

    Why us?
    We are the cable equipment manufacturer
    Professional engineer, long term to research and development for to cable equipment .
    High frequency capacity manufacturer machine is provide .Guarantee the machine all weather running.
    Our machine use the international qualified brand, like Siemens ,Omron,NSK,LG etc.
    Install and training service. Guarantee overseas install and cable manufacture training experience.
    Technical support and spare parts service.


    We DO not only provide the high quality machinery products, but also design the full set of equipment for you.

    PAYMENT:
    1. T/T or L/C (advise)
    2. Wooden packing or PE film sample packing ( Customer requirements )
    3. We 'll do house inspection for every machine before loading it, and also inspected by buyer in person.

    HOW TO REACH OUR FACTORY:
    1.Only 35 minutes from Guangzhou city to Dongguan city by high speed train.
    2.Just 40 minutes from Shenzhen city to Dongguan city by high speed train.
    3.Total 1.5 hours by car from Guangzhou airport to our factory .
    4.Only 0.5 hour by car from Shenzhen airport to our factory.
