    630/12+18 Rigid Stranding Machine With Individual Motor 240rpm Speed

    Ask Lasest Price
    Brand Name : BEYDE
    Model Number : 630
    Certification :
    Payment Terms : T/T
    Supply Ability : 200 Set/Year
    Delivery Time : 90 Days
    • Product Details
    • Company Profile

    630/12+18 Rigid Stranding Machine With Individual Motor 240rpm Speed


    630/12+18 Rigid Stranding Machine With Individual Motor 240rpm.


    APPLICATION 1:
    The Rigid Strander/Cabler is suitable for the concentric assembly of: Stranded conductors for low, medium and high voltage
    applications, Cabling insulated conductors for control cables, Screened power cables and Steel wire armouring.


    APPLICATION 2:
    Round compacted function;
    Prespiralled sector cores for Milliken;
    Overhead conductors (AAC, ACSR, AAAC, ACCC, ACSS…);
    Steel wire armouring;
    Copper wire screening;
    Flexible Class 5;
    Control Cable.


    Characteristics
    1.After technical transformation and optimization design, the speed of the winch box has been increased by more than 15%, and its technical performance has been greatly improved.
    2.It is suitable for the untwisting of copper conductor, aluminum conductor and ACSR, as well as insulated wire and strand. Equipped with roller, also suitable for stranded round, semi-circular, fan-shaped copper or aluminum conductor.
    3.It is applicable to PND 500 type bobbin, equipped with suspender and electric hoist to load and unload bobbin respectively or side bottom loader to load and unload bobbin together.
    4. equal positions on the circumference of the stranding cage are respectively loaded with the bobbin to facilitate loading and unloading. The machine has high rigidity, good integrity, small moment of inertia and fast running speed.
