    High-Standard Drum Twister Machine For Stranding And Wrapping Of Large Cross-Section Power Cables

    High-Standard Drum Twister Machine for Stranding and Wrapping of Large Cross-Section Power Cables


    1. Application:

    This machine is mainly used for the stranding of large cross-section and long power cables and split conductors, as well as the wrapping of non-metallic tape.

    2. Main parameter:


    Conductor shapeRound and sector
    Stranding conductor section16mm2 to 300mm2
    Max laying ODØ20- Ø100mm
    Laying pitch range200-5000mm
    Pay-off rotation speed50r/min
    Drum take-up rotation speed50r/min
    Rotation caterpillar speed50m/min
    Max haul-off force5000kg
    Non-metallic taping unit max rotation speed650r/min
    Taping unit pitch0-200mm(Step-less adjustable)
    Metallic taping unit max rotation speed550r/min
    Metallic taping unit pitch0-200mm(Step-less adjustable)
    Rotating Pay-off bobbin sizePN1250-PN1600
    Rotating Pay-off bobbin sizePN2000-PN2500
    Drum type Take-up bobbin sizePN2000-PN2500
    Filling rope pay-off specificationØ400* 22*360mm (20 pcs)
    Ø630* 52*475mm (4 pcs)
    Steel wire armoring pay-off bobbin sizeØ500
    Ø1600 Rotating Pay-off Motor power15 KW(AC motor)
    Ø2500 Rotating Pay-off Motor power22 KW(AC motor)
    Taping unit Motor power11KW(AC motor)
    Rotation caterpillar motor power18.5kw*2 (AC v motor)
    Drum type Take-up motor power45KW(AC motor)



    Electrical control system

    4.13.1 The main control cabinet is operated by touch screen PLC to coordinate and control the various parameter settings of each unit during the cable forming process, and can display the operating speed and parameters of each unit in real time, facilitating timely modification and adjustment of the operating parameters of each unit.

    4.13.2. The power supply is a three wire five phase system 380V (± 10%) 50HZ

    4.13.3. Working principle of electrical appliances: All driving motors are equipped with encoders, and the encoder feedback runs in the control system. The entire machine is controlled by PLC: the frequency converter, braking unit, air compressor, etc. complete the start-up, jog, normal parking and other operations, ensuring stable synchronization performance.

    4.13.4. Safety protection: This machine has multiple safety protections, which can take corresponding protective measures in case of faults or situations that do not meet the normal operation of the equipment, and timely display the fault point on the screen of the main control cabinet, so that operators can make timely and accurate judgments and effective treatment plans.

    • Protection of the main transmission system, motors, and fans
    • Horizontal limit protection for each wire collection and release rack
    • Traverse overtravel protection
    • Meter counting stop protection
    • Air pressure undervoltage protection
    • Complete wire machine shutdown protection
    • Tape breakage and completion protection
    • Opening the protective cover around the package for protection
    • Hydraulic lifting platform limit protection

    1. Air source requirements

    5.1. Air pressure: 0.6MPa

    5.2. Air volume: 1.0m ³/ Min

    1. Compressed air should be dry, free of impurities and dust

    7. Mechanical and electrical accessories

    7.1Bearing brandHBR
    7.2Main drive motorJIANGHUAI
    7.3Touch screenSIEMENS
    7.4PLCSIEMENS
    7.5Inverter brandINOVANCE
    7.6Low voltage electrical componentsSCHNEIDER
    7.7Pneumatic componentAIRTAC

    8. Document with machine

    8.1Operation and maintenance manual1 pc
    8.2Foundation diagram1 pc
    8.3Overall diagram1 pc
    8.4Electrical drawing1 pc
    8.5Air circuit layout1 pc
    8.6Lubrication diagram1 pc
    8.7Electrical panel diagram1 pc
    8.8AC driver instructions1 pc
    8.9Bearing list1 pc

    9. Operating direction: Right hand, i.e. facing the equipment, pay-off on the left and take-up on the right.
